PRODUCTS - DISPLAY



Introduction
Super thin panel, saving space
High Transparency, display without blocking line of sight
Self emission, low power consumption
Very wide viewing angle
High weather resistance, without effecting of temperature and humidity
Quick responding time, no video residual
Easy using, with blue tooth or RS-232 to change the information

Features
Ultra Slim Structure
Wide Viewing Angle
See-Through Vision
Light Self Emission, Low Power Consumption
Superior Environment Resistance
Fast Response Time
Low Heat Generation, Robust Structure
Modular Design, Flexible Custom Design
Specifications
Diagonal Size
8" (modular unit)
Structure
Diode
Display Area
160 mm x 160 mm
Resolution
32 x 32 dots
Pixel Pitch
5 mm x 5 mm
LED Color
Monochrome (R/G/B)
Brightness
>=300 cd/? (Green)
Transparency
>=85%
View Angle
>=175°
Power Consumption
Normally 3W, Max. 5W
Operation Temperature
-20? ~ 60?
Panel Outline Dimension
178 (H) mm x 224 (W) mm x 5.7 (D) mm
Demo Kit Outline Dimension
202 mm x 268 mm x 53 mm
Lifetime
10,000 hours
Control Way RS-232
USB (optional)



Specifications
LED dot size
3mm
LED color
Red
Dot pitch
4.6 mm
Dot matrix
5 dots (W) x 7 dots (H)
Material
Main rack & keel are aluminum, front & backsides are metal.
Resolution
120 (W) dots x 7 (H) dots per line
Display area
55.2 cm (W) x3.22 cm(H) x 7 lines/ 55.2 cm (W) x3.22 cm(H) x 8 lines
Cabinet size
680 mm (W) x1860 mm(H) x150 mm(D)
Maximum characters
20 characters per line (for 5 x 7 dots character font) total 7/ 8 lines per set
Viewing distance
20M Max.
Power consumption
Normally 80W, Max. 250W
Power input
AC 110V/ 230V
Control way
By IR/ 55 keys
By RS-232 built in windows software attached. (Optional)
Illuminated logo (Optional)


Types
Pitch 10 Indoor Type
Pitch 16 Indoor/Outdoor Type
Pitch 20 Indoor/Outdoor type
Pitch 22 Indoor/Outdoor type
Pitch 25 Indoor/Outdoor type
